Model A15-MH069 is an ultra-fast miniature SDLVA. In slightly over 2.0 cubic inches, the unit features 60 dB dynamic range and exceptionally fast 40 nanosecond fall time.
| Model Number | A15-MH069 |
|---|---|
| Frequency Range (GHz) | 2.0-18.0 |
| Dynamic Range (dBm) | 60 |
| T.S.S (dBm) | -66 |
| Logging Range (dBm) | -60 to 0 |
| Frequency Flatness (dB) | +/- 2.0 (max); +/- 1.75 (typ) |
| Log Linearity (dB) | +/- 1.5 (max); +/- 1.0 (typ) |
| Log Slope (mV/dB) For Linerity Measurement | 15 |
| Rise Time (nS) | 10 |
| Fall Time (nS) | 40 |
| Propagation Delay (nS) (50% RF to 10% Video) | 10 |
| Recovery Time (nS) (90% to +/- 1.0 dB of Baseline) | 125 (typ); 200 (max) |
| Power Supply(VDC) | +12 @ 500mA; -12 @ 125mA |
| Coupling | DC |
| Operating Temperature (°C) | -20 to +71 |
| VSWR | 2.0:1 (max) |
